Hoist-type carbonizing stove for wood
Carbonization furnace is used for charring biomass briquette into
smokeless charcoal briquette.This furnace is ideal equipment for
wood briquettes to have anoxic distillation carbonization. Due to
its rational structure, the furnace only needs little heat
consumption.Energy that comes from firewood or gas heating.
Carbonization furnace is used for charring biomass briquette into
smokeless charcoal briquette.This furnace is ideal equipment for
wood briquettes to have anoxic distillation carbonization. Due to
its rational structure, the furnace only needs little heat
consumption.Energy that comes from firewood or gas heating.
The hoist loading carbonizing stove is our new invent, which is
also combined type. The charcoal can be hoisted outside, in this
way the cooling time can be reduced much, thus, the productive
efficiency increases a lot. It is the ideal choice for mass
production of charcoal.
This type of carbonizing stove adopts the structure of unique air
storage chamber, to fully reuse the smoke produced during the
process of carbonization. And 60% of the redundant smoke can be
used in drying and carbonizing, saving much fuel during the whole
process, and increasing the enterprise revenue.
Model | Capacity of stick(kg) | Final production of coal(kg) | Time of carbonization(h) | Time of cooling(h) | Total time | Weight(including the inner pot) |
Dimension |
DZ-260 | 650 | 260 | 6--8 | 10 | 16-18 | 2.2T | 1.55*1.55*2.07m |
DZ-500 | 1250 | 500 | 6--8 | 12 | 18-20 | 2.8T | 1.92*1.92*2.07m |
DZ-1000 | 2500 | 1000 | 10—12 | 24 | 34-36 | 3.7T | 2.2*2.2*2.22m |
About packaging, we can offer free fumigation wooden case with
steel frame, which is very
strong, not only can protect machine from damage, but also avoid
checking when exporting.
For multiple machines, or production line, it's better to loaded in
standard container 20GP,
40GP, usually it needs wrapped with plasitc firstly, then loaded in
container.
About shipping, we can offer EXW, FOB and CIF terms.
EXW: We offer machines to you, and you arrange the shipping details
by yourself.
FOB: We arrange freight transport to Qingdao, Shanghai or other
ports of China, then you
arrange the shipping details from China port to your country port.
CIF: We arrange shipping details to your country port, and ensure
machines smooth arrival.
Project of sawdust briquette charcoal machine:
We have oversea installation service.our engineer will guide you to
install and operate
machines,train your workers face to face
