    500kg/H Crushing Scrap Copper Wire Recycling Machine

    Ask Lasest Price
    Brand Name : SANJIN
    Model Number : HD-600
    Certification : CE ISO
    Price :
    Payment Terms : L/C, T/T, Western Union
    Supply Ability : 9 Set/Sets per Month
    Delivery Time : 3-7 days
    • Product Details
    • Company Profile

    500kg/H Crushing Scrap Copper Wire Recycling Machine

    Electric Cable Copper Granulator Wire Recycling Machine / Granulate Of Copper Separator Equipment


    Technical parameters of Electric Cable Copper Granulator Wire Recycling Machine

    ModelCapacity(kg/h)Power(kw)Fan(kw)
    HD-600400-50018.53
    HD-800700-800304
    HD-1000800-1000375.5

    500kg/H Crushing Scrap Copper Wire Recycling Machine

    500kg/H Crushing Scrap Copper Wire Recycling Machine

    500kg/H Crushing Scrap Copper Wire Recycling Machine


    Working principle of Electric Cable Copper Granulator Wire Recycling Machine

    Under the action of wind force, two kinds of materials with different densities, through the deflection generated by the amplitude movement on the screen surface at a certain Angle, the dense copper wire moves forward facing the outlet, and the low-density plastic skin floats on the copper wire and flows to the outlet, so as to achieve the purpose of separation of copper and plastic. The clean rate of separation is proportional to the diameter of a single copper wire, the thicker the diameter of a single copper wire is, the cleaner the separation of plastic is, while the thinner the diameter of a single copper wire is, the worse the separation effect of plastic is


    Feature of Electric Cable Copper Granulator Wire Recycling Machine
    1. High degree of automation, easy operation (manual or automatic

    2. Recovery rate up to 99%.

    3. The dry pulverizer produces 99% copper.

    4. Long service life of the machine, just replace the wearing parts.

    5. High cost performance of machinery can be processed in large scale (the finest wire can be separated)

    Applied raw material of Electric Cable Copper Granulator Wire Recycling Machine

    Wire and cable equipment is used for all kinds of automobile electric line communication cables and so on all kinds of cable and wire stripping machine is not suitable for processing all kinds of miscellaneous cables, broken thoroughly the copper and plastic separation, after the equipment energy conservation and environmental protection, no dust pollution, can effectively deal with a lot of waste miscellaneous line, and to achieve the comprehensive utilization, has high economic benefit
